[This blog posting is extracted from a project backer email sent on April 18, 2021, and is being published here as an example of the kind of content you can expect if you back this project. Via new support from Sustrans and the Department for Transport we aim to bring back to life 100s of miles of 1930s-era cycleways.]
Three parallel cycleways run through or beyond the Lancashire town of Formby. There’s NCN 810, a wiggly on-road route through the centre of town. And there’s NCN 62, an off-road route on the former trackbed of the Cheshire Lines railway to the east of Formby. Smack bang through the middle of these two is the cycleway on the Formby bypass. This is not part of the National Cycle Network, so it is not on the NCN layer of the Ordnance Survey map of the area.
Today’s Formby bypass has cycleways on both sides of the road only on some short sections. However, when the four-mile dual carriageway was opened in 1938, the bypass had wide, well-surfaced, and fully adjacent cycleways. The missing sections are now probably buried under grass.
The A565 Formby bypass is one of the 1930-era cycleways on our long-list for possible renovation. One of the upgrades needed would be to dig up and rededicate the missing sections.
Back in the 1930s, the bypass had 6-ft-wide footways adjacent to 9-ft-wide cycleways. A period document reveals that the footway had a pink asphalt surface, and the cycleways — known at the time as cycle tracks — had a non-skid green asphalt surface. The road surface was concrete, laid in 46-feet-long bays. Today, the cycleway — like the road — has a black asphalt surface; the footpaths remain buried.
Many of the 1930s cycle tracks I’ve been researching were surfaced with rippled concrete, so it’s interesting to discover the period surface smoothness of the Formby tracks; to learn that they were green adds to the surprise.
There doesn’t seem to have been any prescribed colour for cycle tracks in the 1930s and 1940s — for instance, the concrete cycle tracks on Lostock Road in Manchester were red, but many others were uncoloured.
The Formby bypass was considered such a technological innovation at the time that Lancashire County Council produced a 16-page commemorative brochure for the opening of the road, packing it with the kind of detail I’d usually kill for.
The bypass was opened with great civic pride at midday on Saturday, December 17th, 1938, and a map included in the brochure even pinpointed the exact location of the dais from which the Earl of Derby, Lord Lieutenant of Lancashire, gave a ribbon-cutting speech to a “large assembly.”
“On the covered stand erected for the occasion,” stated a December 17th report in Formby Times, “was grouped a representative company of county and local notabilities.”
Alderman P. Macdonald, the vice-chairman of the county council’s highways committee, said the bypass was “laid out on the most modern lines and constructed according to the requirements of the Ministry of Transport.”
It was the MoT that stipulated that the road should be equipped with cycle tracks. It had been initially planned in 1928 as a narrower road without cycle tracks. For the ten years from 1934 to 1944, the MoT tended to only give road-building grants to those local authorities which incorporated cycle tracks into their arterial widenings and new-builds.
“Whilst it cannot be claimed that this road is an industrial road, it does carry a very considerable weight of through commercial traffic between the great city of Liverpool and the beautiful town of Southport,” continued Macdonald.
That commercial traffic included cyclists, of course, of which there were an increasing number in the ten years before the building of the bypass. A traffic census conducted on the old road — the findings of which were included in the brochure — counted 530 cyclists in 1928, and 2,291 in 1938, a four-fold increase. In the same period, motor car use merely doubled. There were just under a thousand more motor cars than bicycles on the road before the bypass was built. And cyclists were far more numerous than the combined number of trucks, buses, motorcyclists and horse-drawn vehicles.
Given the explosive growth in the use of bicycles — the growth was national — you would think more would have been done to cater to cyclists during the 1930s. Instead, most national and local resources were splashed on motorists. As I wrote in Bike Boom, “Two million rich motorists were deemed to be worthier than twelve million proletarian cyclists.”
Today, because by design motoring was encouraged to grow, it’s a surprise that the pre-war MoT did anything at all for cyclists.
Very fine road
The bypass, said Macdonald, reported in Formby Times, was “divided, as you see, by two carriageways with a central reservation and a cycle track on either side, along with a good footpath.”
The newspaper said he hoped that “by this segregation of traffic that accidents will be reduced, that the flow of traffic will be facilitated, and the comfort of users will be added to.”
The highways committee vice-chairman thanked those “who had contributed to the making of that very fine road,” stated the Formby Times. He praised the county surveyor Mr. Schofield, his chief assistant, Mr. Wordsworth, Mr. Haywood, resident engineer, and building supervisor Mr. Gore working for W. Turner (Ardwick), Ltd., of Manchester.
“He then asked Lord Derby,” reported the paper, “to step down into the roadway and formally declare the road open as the King’s Highway for all time.”
According to the commemorative brochure, the four-mile-long road was 120 feet wide “between fences” with dual carriageways 22 feet wide. There was also a central reservation of 22 feet (which, it appears from Google StreetView, has been much nibbled away over time) and “cycle tracks nine feet wide and footpaths six feet wide, with grass margins.”
The bypass cost £195,483, “towards which the Ministry of Transport indicated a grant of 60% on 17th April, 1936,” stated the brochure.
“Work was commenced on April 9th, 1937 [and] the bulk of the general contract work was completed by September 1938,” said the brochure, adding that 75 men had been employed on the scheme.
“The carriageways have been constructed of concrete, 12 inches thick (which forms the running surface), laid on a consolidated bed of clinker ballast 9 inches thick,” stated the brochure.
To delight today’s kerb-nerds, the brochure continued: “Splayed kerbs are provided on each side of the central reserve as a safety measure. The near side kerbs joining the cycle tracks are 10 inches by four inches and are laid directly on the extremity of the concrete carriageway slabs.”
The cycle tracks were constructed with “6 inches consolidated foundation of clinker ballast covered with a binder course of tarmacadam [one and a half] inches thick over which is laid a [three-eighths-inch] layer of sand carpeting, squeegeed with bituminous compound and covered with [three-sixteenths of an inch] gauge green chippings evenly distributed and lightly rolled to produce a matt, non-skid surface finish.”
Furthermore, the “near-side concrete kerb of the cycle tracks is set sufficiently low to prevent cycle pedals from coming into contact with it. And the offside timber kerb is fixed flush with the surfaces of the cycle track and adjacent grass margin so that it can be overrun in the case of an emergency.”
Timber kerbs? That’s new information to me. Perhaps other period cycleways had similar demarcation? If so, any non-replacement of rotted wooden kerbs would clearly hasten track decay.
“The footpaths are constructed in a similar manner to the cycle tracks,” continued the brochure, “except that the foundation of clinker ballast is three inches thick and the squeegeed surface of the sand carpeting is covered with half inch gauge pink chippings.”
The surfacing of the carriageways, cycle tracks, and footways was carried out by Cawood, Wharton & Co., Ltd., of Leeds, stated the brochure. The surfacing materials for the cycle tracks and footways were supplied by the Penmaenmawr and Trinidad Lake Asphalt Co. Ltd. of Caernarfon, Wales.
As can be seen on the Google Map for this project, the Formby bypass is one of several 1930s-era new-builds nearby with adjacent cycle tracks. To the north, there was the Coastal Road to Southport, and to the south east, there were cycle tracks on Dunnings Bridge Road in Litherland, and on the A59 at Aintree, Maghull and Aughton. Perhaps more remain to be discovered?
Should the Formby bypass make it on to our shortlist, and then on to recommendation for an upgrade, any renovations would create a helpful route linking to housing on the east side of Formby; housing that didn’t exist in 1938.
